I
ELECTRICAL SYSTEM
c. Tum the horizontal a1mmg screw, located on
the side of the lamp housing, counterclockwise
until the beam is off. T hen, tum the same screw
clockwise
until the center of high intensity is
equally divided by the vertical reference line. See
Fig. 170.
d . Cover the lamp that has been aimed and aim
the other lamp using the same procedure.
e. Garefully reinstall the head lamp doors.
06t AHCl \4MI: "'
lAJoO.t(tNf ll
flfi0Mfi()()4t
1 0038
FIG. 170-HEADL I GHT AIMING CHART
FOR SOOO·SERIES LAMPS
1- 75. Aim i ng 6000- se ri es He ad Lamp s
a. Tum the headlights on low beam. Cover the
lamp not being aimed. Be sure to use the horizontal
reference line on the screen that is the same dimen-
sion as the vehicle lamp height.
b. Tum the vertical aiming screw counterclock-
wise un til the lamp beam is considera bl y l ower
than the horizontal ref erence line on the screen.
Then, turn the screw clockwise until the top edge
of the high intensity area is even with the horizontal
line. See Fig. 171.
/ ,.. .. ..
,q /' g/
7
V EA TI C: At.. TAP £
. ..
10333
F IG. 171- H EADL IGHT AIMING CHART
FOR 6000- SERIES LAMPS
Not e : Always bring th e beam into final position
by turning bot h aiming screws clockwise so that
the unit is held under proper tension when the
operation is complete.
c. Tum the horizontal " aiming screw coun terclock-
wise until the beam is off. Then, tum the same
screw clockwise until the left edge of the high
148
intensity area is 2" [50,8 mm.] to the right of the
lamp center line. See Fig. 171.
d . Cover the lamp that has been aimed and aim
the other lamp using the same proc e dure.
e . Carefully reinstall the head lamp doors.
1 -7 6. Horn
All models are equipped with an electric warning
hom which is mounted under the hood on the left
front fender. T he hom is sounded by pressing the
button lo cated at the top center of the steering
wheel.
To remove the horn wire, disconnect the wire at
the snap connection at the base of the steering
column. Pull off the rubber hom button cap and
the brass contact c ap from the steering wheel nut.
This will expose the contact tip of the hom wire.
Pull the wire out of the steering colum n from the
top.
Up to Serial No. 178361 the Model CJ-2A hom
wire passes through the steering tube and connects
to an insulated sleeve wi th a br u sh contact mounte d
on the steering outer tube.
FIG. 172-HORN BUTTON
! --c ap
2- Nut
3- Horn Button Spring Cup
4- Fe r rule
S- Horn Ca ble
6- Contaet D i oc
?- Steering Wheel
8- Cup
9- &aring Spring Seat
10 -5 teering Column
11- Tube
12 - &aring
13 - &aring Spring
14 - Horn Button Spring
IS- Retainer Spring
Sho ul d it be necessary to r ep lace t he ho m wi re, it
will
be necessary to r emove the steering colu mn.
The wire may be removed by unsoldering it from
the contact sl eeve on t he steering tube. W hen re-
