4.3 Internal I/O Circuit
INPUT 1-4
OUTPUT 1-2
TYPE SOURCE
SOT
Bit-value
TYPE
SOA
Bit-value
ACTIVITY
Output
ON
Output
OFF
0,1
SOURCE
1
HIGH
24V*
open*
0
LOW
open
24V
4.4 Output Configuration
ACTIVITY
SOA (Set Output Activity) parameter 2 Bit
1 Bit-value per output
Output
2
1
SOA Bit
1
0
Bit-Wert
1
1
Decimal
3
*Default setting all outputs set to HIGH ACTIVE
>SOA 3
HIGH or LOW ACTIVITY programmable
INPUT 1-4
24V, Ri = 31kΩ
