POWER Amplifiers
7
Power 760/920
Four Speakers
Two Speakers and Bridged Subwoofer
Two Subwoofers
4 ohm nominal
2 ohm minimum
4 ohm nominal
2 ohm minimum
+ CH1 - + CH2 -
+ CH3 - + CH4 -
+ BRIDGED -
X-OVER
FULL
LPF
HPF
FULL
LPF
HPF
4 ohm nominal
2 ohm minimum
4 ohm nominal
+ CH1 - + CH2 -
+ CH3 - + CH4 -
+ BRIDGED -
X-OVER
FULL
LPF
HPF
FULL
LPF
HPF
4 ohm nominal
4 ohm nominal
+ CH1 - + CH2 -
+ CH3 - + CH4 -
+ BRIDGED -
X-OVER
FULL
LPF
HPF
FULL
LPF
HPF
