LOC ATION OF CONTROLS
1. Alarm 1
Button
Alarm 2 Button
2. Access Opening for Top Compartment
3. T ime Set/ Memory/ Display Button
4. Sleep But ton
5. Snooze/ Dimmer/ Phone Button
6. Play/ Pause / Memory / Pairing Button
7. Skip Forward / Tuning Up Button
Skip Backward / Tuning Down Button
8. Volume + (Up) Button
Volume - (Down) Button
9. Power On/ Standby / Source Button
10.Speaker
11.LCD Display
16
7
8
9
2
3
4
5
10 11
TOP SIDE
FRONT SIDE
E-3
