E-4
T
he JCR-295 operates with an external AC-DC adaptor with a rating of DC 5V, 1200mA .
The system is also equipped with a battery back-up system for the clock that is powered by 2
pieces of “AAA” (UM-4) size batteries (Not included).
Note : The batteries may be installed as a backup option to maintain the clock time if electrical
power fails. In the event of power outage, the clock time will not be displayed, however
the clock will continue to operate so current time will be maintained.
AC OPERATION
The JCR-295 only operates using the AC-DC adaptor. Be sure to use an AC-DC adapter
with a rating of DC 5V, 1200 mA and with the following polarity:
If you are using a universal adaptor with an output polarity switch or polarized plugs, be
sure to set the polarity of the center plug to "
+".
WARNING : Never use this radio near water or in the shower when using an AC adaptor.
Shock or personal injury could occur.
INTALL BACKUP BATTERIES
1. Remove the Battery Door on the bottom of the unit.
2. Following the polarity diagram as shown inside the battery compartment (#7), insert 2
AAA size batteries (not included ) and replace the door.
1. Only an adult should replace the batteries.
IMPORTANT:
Be sure that the batteries are installed correctly. Wrong polarity may damage the unit.
2. Use only the size and type of batteries specified.
3. For better performance and longer operating time, we recommend the use of
alkaline-type batteries.
4. Do not mix old and new batteries.
5. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
6. If the unit is not to be used for an extended period of time, remove the batteries.
7. Old or leaking batteries can cause damage to the unit and may void the warranty.
8. Do not dispose of batteries in fire, batteries may leak or explode.
9. Do not try to recharge batteries not intended to be recharged, they can overheat and
rupture. (Follow battery manufacturer’s directions.)
POWER SOURCE (AC ADAPTER ONLY)
