Jensen JEP-150 - Product Controls and Setup; Location of Controls Overview

E-5
LOCATION OF CONTROLS
1 TIME/M+ 10 FM INDICATOR
2 MIN/DOWN/DIM 11 AM INDICATOR
3 HOUR/UP 12 ALARM 1 INDICATOR
4 SNOOZE/SLEEP 13 ALARM 2 INDICATOR
5 VOL-/AL1 14 PM INDICATOR
6 VOL+/AL2 15 BATTERY DOOR
7
/MODE
16 AC POWER CORD
8 ALERT INDICATOR 17 ANTENNA
9 WB INDICATOR
