E-5
LOCATION OF CONTROLS
1 CD DOOR (OPEN/CLOSE) 11 AUX IN JACK 21 PROG. / PRESET + BUTTON
2 LCD DISPLAY 12 HEADPHONE JACK 22 SPEAKERS
3 TUNING - BUTTON 13 DOOR 23 HANGER HOLES
4 TUINING + BUTTON 14 PLAY/PAUSE / SCAN
BUTTON
24 FOLD OUT SPEAKER
STANDS
5 STANDBY BUTTON 15 SKIP/SEARCH FORWARD
BUTTON
25 FM ANTENNA
6 TIME ADJ BUTTON 16 STOP / MEM. BUTTON 26 REMOVABLE STAND
7 AL. ON/OFF / SLEEP BUTTON 17 MODE BUTTON 27 BATTERY DOOR
8 VOL + / MIN. BUTTON 18 SKIP/SEARCH BACKWARD
BUTTON
28 AC POWER CORD
9 VOL - / HOUR BUTTON 19 REPEAT / PRESET -
BUTTON
29 SPEAKER CABLE
10 AL. SET / AM/FM BUTTON 20 REMOTE SENSOR 30 SPEAKER CABLE
