Jensen JTA-455 - Setup and Controls Overview; Accessories Included; Location of Controls; AC Operation

E-5
ACCESSORIES INCLUDED
- Application CD
- USB cable
- 45 RPM Record Adapter
- User Manual
LOCATION OF CONTROLS
Caution:
Usage of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service
personnel.
AC OPERATION
1. Connect the AC POWER CORD (#15) to an AC outlet.
2. Rotate the POWER ON/OFF AND VOLUME CONTROL KNOB (#7) clockwise to turn
on the system. The POWER INDICATOR (#6) will light up.
1
DUST COVER
2
ANTI-SHOCK LOCK DOWN
SCREW
3
45 RPM ADAPTER
4
AUTO STOP SWITCH
5
33/45/78 RPM SPEED
SELECTOR
6
POWER INDICATOR
7
POWER ON/OFF AND VOLUME
CONTROL KNOB
8
BLUETOOTH BUTTON
9
BLUETOOTH LED INDICATOR
10
TONE ARM LIFT
11
USB PORT FOR COMPUTER
CONNECTION
12
RCA LINE-OUT JACKS
13
AUX-IN JACK
14
HEADPHONE JACK
15
AC POWER CORD
