13
VM9214
Parking Brake Inhibit
When the pink "Parking" wire is connected to the vehicle Parking Brake circuit,
the front TFT monitor will display video when the Parking Brake is engaged.
(When the pink wire is grounded via the Parking Brake circuit, video will be
displayed.)
Monitor Movement Mechanism
If an obstruction occurs in the monitor path, the following protective
measurements can be executed to prevent damage to the mechanism or
monitor:
After the protective procedure is executed, normal operation is resumed by
pressing the OPEN button (1) or disconnecting and reconnecting the power.
Table 3: Monitor Protective Measures
Obstruction Self Protection
OPEN Button
Pressed
Power
Reconnected
Monitor loading
out horizontally
Monitor is automati-
cally loaded into unit
Monitor fully
extended horizon-
tally
Monitor is automati-
cally loaded into unit
Monitor loading in
horizontally
Unit stops at
obstruction point
Monitor fully
extended horizon-
tally
Monitor is automati-
cally loaded into unit
Monitor loading
out vertically
Unit stops at
obstruction point
Monitor swivels
back to the unit
Monitor swivels
back to the unit
Monitor loading in
vertically
Unit stops at
obstruction point
Monitor swivels
back to the unit
Monitor swivels
back to the unit
