31
VM9224
For example, a medium with the following folder/file hierarchy is subject to
Folder Search, File Search or Folder Select, as shown below.
The VM9224 player will only recognize three folder levels and does not display
folders containing only other folders. In the example above, the unit will display
folders 3, 4, 6, and 8, but not 2 and 7 since they do not contain any tracks
directly. Folder 5 is not recognized at all since it is at the fourth level.
Inserting a USB Device or SD Card
NOTE: The USB port will recognize most USB flash memory devices and
portable hard drives (hard drives must be formatted to FAT32, NTFS is
not supported).
1. Locate the USB/SD connector cover (8) on the front of the radio.
2. Lift the protective cover to reveal the connectors.
Type A USB
Connector
OPEN
MUTE
