Jerr-Dan MPL-NG User Manual

Section 7 : Specications
5376000253 7-1
SECTION 7 - SPECIFICATIONS
7.1 PRODUCT SPECIFICATIONS
MPL-NG
OPERATING SPECIFICATIONS AND PERFORMANCE DATA
DO NOT EXCEED THE FOLLOWING RATINGS:
BOOM RATING:
SAE J2512 Rating - Boom elevated at 30° Angle
1
....................................8,000 lbs.
WINCH RATING: (Standard Worm Gear) ..................................................8,000 lbs.
2
WIRE ROPE: (Standard)
Working Limit Each Line ................................................................. 4,300 lbs.
Construction ................................................................6 x 25 EIPS RRL IWRC
Diameter ............................................................................................ 3/8 inch
Standard Length ................................................................................. 75 Feet
WIRE ROPE: (Optional)
Working Limit Each Line ..................................................................4,300 lbs.
Construction ................................................................6 x 25 EIPS RRL IWRC
Diameter ............................................................................................ 3/8 inch
Standard Length ................................................................................110 Feet
UNDERLIFT RATING: (Reference underlift serial number tag)
Full Extended .............................................................................. ....4,000 lbs.
Tow Rating ......................................................................................7,500 lbs.
5th WHEEL ATTACHMENT (OPTIONAL WITH HYDRAULIC GRIDS ONLY):
Lifting Capacity ............................................................................... 4,000 lbs.
Towing Capacity ................................................................. .. ...... .... 7,500 lbs.
GOOSENECK ATTACHMENT (OPTIONAL WITH HYDRAULIC GRIDS ONLY):
Lifting Capacity ............................................................................... 4,000 lbs.
Towing Capacity ................................................................. .. ...... .... 7,500 lbs.
TOWBALL HITCH:
1-7/8 in. Ball (OPTION)....................................................... ..5,000 lbs. (GTW)
2 in. Ball (OPTION) ............................................................. ..5,000 lbs. (GTW)
2-5/16 in. Ball (OPTION)..................................................... ..7,500 lbs. (GTW)
50 mm. Ball (OPTION) ........................................................ ..5,000 lbs. (GTW)
GROSS TRAILER WEIGHT ........................................3,000 Maximum Vertical Load
