Section II: Operation
Page 55
5-376-000086
REV. 4 - 07/10
CAUTION:
The Bottom Anchor Assembly (round tube) must never be higher
than the attachment point on the rear of the truck. The Stand Off
Bar Assembly acts as a pivot in the event of a sudden stop. This
will assure that the towed vehicle will not catapult forward onto the
deck of the MPL40.
23. After the tow is complete, reverse
the procedures to unload the
vehicle.
24. With the vehicle unloaded and the
tow sling extended, use the
underlift fold function to bring the
tow sling head back up into its
storage position.
25. Rotate the “CAM” handles on the
hold back bars 180° to the open
position.
To Next Page
