Operating manual Page 17
Spare parts ICEB 4-roll wire feed 42V, 130/140/150W
Item
MIG
MIG
Designation
Stock
325
405
Number
1
x
x
master switch S225-647072
440.020.044
2
x
x
coarse weld grade switch S225-647073 2 grades
440.020.042
3
x
x
fine weld grade switch S225-647025 12 grades
440.020.041
4
x
x
case handle
715.055.010
5
x
x
side panel, bottom left
715.055.015
6
x
x
side panel, top left
715.055.013
7
x
x
side panel, top right
715.055.014
8
x
x
side panel, bottom right
715.055.016
9
x
x
bonded tired wheel with starlock cap
720.250.021
10
x
x
guide roll 140 mm dia
301.140.003
11
x
x
choke for MIG 325/405 with connect. cable
706.055.002
12
x
x
heat exchanger 220x250x50 mm
309.361.002
13
x
x
wire feed motor with 4-roller feed 140 W, 42V
454.140.023
x
x
wire feed roll 0.8 - 1.0 for 4-roller feed
454.010.024
x
x
wire feed roll 1.0 - 1.2 for 4-roller feed
454.012.025
x
x
wire feed roll 1.6, knurled type, 4-roller feed
454.016.026
x
x
wire feed roll, plain/knurled, 4-roller feed
454.000.027
14
x
x
Binzel central adaptor (107) compl. f. 4-roller feed
425.107.001
x
x
insulating flange to Binzel central adaptor
425.501.004
15
x
x
wire holding arbor
306.050.003
16
x
x
fan A4E 300, 230 V
450.300.020
x
x
capacitor 1 uF/450 V for fan
453.450.002
17
x
x
manometric switch 0.1 - 1 bar MS, M 10x1
444.166.002
18
x
x
solenoid valvel NW 2,5 / 42 V G 1/8
465.018.009
19
x
x
water pump
456.220.100
x
x
capacitor 6,3 uF/400 V for water pump
453.230.002
20
x
x
water tank
715.055.003
x
x
tank srew cap 40 mm dia
308.400.003
21
x
x
potentionmeter control knob 36 mm dia
711.036.005
x
x
potentiometer control knob 20 mm dia
711.020.004
22
x
x
signal lamp 42V yellow
463.042.011
23
x
x
fuse holder with bayone type sealing cap
464.601.001
x
x
fine-wire fuse 5x20 mm T 2 A
464.025.006
24
x
x
built-in tip jack BEB 35-50
422.031.024
25
x
mains cable 4 x 2.5 mm
2
, 5m, plug 32 A
704.025.021
x
mains cable 4 x 4 mm
2
, 5m, plug 32 A
704.040.014
26
x
x
cylinder supporting chain
101.040.020
27
x
x
control box MS 15-5, complete
851.015.010
x
x
fine-wire fuse 5x20 mm T 6.3 A for control box
464.063.010
28
x
x
contactor DL 11K - 10 / 42 V
442.042.008
29
x
x
rectifier, 12 plates, 4 diodes/plate
461.125.025
x
x
Thermoswitch 90°C (break) for rectifier
445.080.004
x
x
Thermoswitch 50°C (make) for rectifier (only Gas)
445.050.005
30
x
MIG 325 welding transformer incl. cable
722.006.006
x
MIG 405 welding transformer incl. cable
722.006.008
x
x
Thermoswitch 170°C (break) for transformer
445.170.002
x
x
Thermoswitch 80°C (make) transformer (only Gas)
445.080.006
31
x
x
Auxiliary transformer
462.042.016
