Operating manual Page 19
Item
Designation
Stock number
10
Motor armature 140W komplett
457.140.010
Motor armature 150W komplett
457.150.052
11
Ball bearing 12x32x10 mm, 6201 2RS
285.201.001
12
Hexagon head cap screw M4 x 110 for 140W
457.140.012
Stud bolt M4 for 150W
457.150.054
13
Gearbox case
457.140.013
14
Plain washer D 4,3
D125 D4,3
15
Nut M4
D934 M4
16
Securing ring I 32 x 1,5
D472 I32x1,5
17
Ball bearing 10x26x8 mm, 6000 2RZ
285.000.002
18
Securing ring I 32 x 1,5
D472 I32x1,5
19
Nylon gear wheel, helical gearing
457.140.019
20
Wedge 4x5 mm
457.140.020
21
Long face pinion
457.140.021
22
Securing ring I 40 x 1,75
D472 I40x1,75
23
Nylon gear wheel, spur toothed
457.140.023
24
Securing ring E 17 x 1
D471 E17x1
25
Gearbox case
457.140.025
27
Ball bearing 17x40x12 mm, 6203 2RS
285.203.003
28
Distance block
457.140.028
29
Conical nipple 20x40x7 mm
457.140.029
30
Wire guide tube, middle
457.140.030
31
Nut M10
D934 M10
32
Fan type locker wash D 10,5
D6798 D 10,5
33
Wire guide nozzle, metal
457.140.033
Wire guide nozzle, plastic
457.140.032
34
Pressure arm, Alu
457.140.034
35
Base plate for wire feed unit
457.140.035
36
Motor shaft
457.140036
37
Gripping lever, Alu
457.140.037
38
Cap screw M6 x 10
D912 M6x10
38a
Cap screw M6 x 25
D912 M6x25
39
Securing ring E8 x 0,8
D471 E8x08
40
Countersunk head screw M6 x 20
D7991 M6x20
41
Driving toothed wheel for wire feed roll
457.140.041
41a
Compensation washer D13 x 19 x 0,1 mm
D988 13x19x0,1
Compensation washer D13 x 19 x 0,2 mm
D988 13x19x0,2
42
Wire feed roll, top
look spare parts
43
Fixing washer for feed roll
457.140.047
44
Wire feed roll, bottom
look spare parts
50
Motor end covering complete with brush holder 140W
457.140.045
Motor end covering complete with brush holder 150W
457.150.050
51
Motor 130W complete with gearbox case
457.130.060
Motor 140W complete with gearbox case
457.140.003
Motor 150W complete with gearbox case
457.150.053
52
Gear complete with gearbox case
457.140.048
53
Wire actuation complete, without feed roll
457.140.049
