22-44 OSCILLATING
DRUM SANDER
jettools.com
Variable Feed
control produces the
ultimate finish
Built-in cabinet door
for easy access
to storage
98-0060 98-2201
Height Adjustment Handwheela.
1-3/4HP TEFC Motorb.
Exclusive Sand Smartc.
®
Variable
Speed
Conveyor Bedd.
Self Cooling Drume.
4" Dust Portf.
B
C
A
D
F
Features
Oscillating feature reduces heat build-up on sanding belt to reduce
loading and burning
Our EXCLUSIVE SandSmart™ infinitely variable-feed control
produces the ultimate finish at a rate from 0 to 10 feet per minute
and prevents machine overload
Patented conveyor belt TRACKERS™ dramatically reduce the need
for manual belt adjustments
22" wide suspended drum is supported on both ends with a cast iron
carriage arm for greater strength and easy alignment to the table
surface for consistent performance
Sealed and permanently lubricated drum ball bearings for longer life
Precision-flattened reinforced steel conveyor bed and no-give power
feed belt provide a constant smooth sanding action for better results
Adjustable drum height and downward pressure feature virtually
eliminates snipe
Large cast-iron handwheel adjusts height at 3/32" per turn for
precise sanding thickness control
Patented abrasive take-up fasteners make changing abrasives quick
and easy
Depth gauge has locking stop to ensure accuracy
On/off switch with overload protection is front-mounted for
operator's convenience
One feed and one drive motor for superior sanding control
Continuous-duty, 1-3/4HP motor is designed for heavier use for
longer periods of time
aCCessOrIes
Infeed/Outfeed Tables
98-2201
Tuf Tool
98-0060
speCIFICatIOns
Stock Number
659006K
Model Number
22-44 OSC
Style
Closed Stand
Max. Board Width (in.)
44
Max. Board Thickness (in.)
4
Min. Board Length (in.)
2-1/4
Min. Board Thickness (in.)
1/32
Drum Diameter (in.)
5
Drum Length (in.)
22
Drum Speed (RPM)
1700
Conveyor Speed (SFPM)
0 to 10
Conveyor Motor
43 in.-lbs. torque, direct
drive, dc
Dust Port Diameter (OD/in.)
4
Amps
9
Motor HP
1-3/4
Motor Phase
1
Motor Voltage
115
Prewired
115V
Net Weight (lbs.)
360
E
