4.0 Specifications

Model number ................................................................................................................................................... HVBS-56

Stock number ....................................................................................................................................................... 414458

Motor and electricals:

Motor type (UL listed) .............................................................. totally enclosed fan cooled, induction, capacitor start

Horsepower .................................................................................................................................... 1/2 HP (0.37 kW)

Phase ............................................................................................................................................................... single

Voltage ............................................................................................................................. 115/230V (prewired 115V)

Cycle .................................................................................................................................................................. 60Hz

Listed FLA (full load amps) ............................................................................................................................. 9/4.5 A

Starting amps ................................................................................................................................................... 10.1 A

Running amps (no load) .................................................................................................................................... 4.9 A

Start capacitor ................................................................................................................................ 200MFD 125 VAC

Power transfer ................................................................................................................................................... v-belt

On/off switch ..................................................................................................................................................... toggle

Motor speed ............................................................................................................................................... 1720 RPM

Power cord.............................................................................................. SJT 3x18AWG, 300V, length 6 ft. (183 cm)

Power plug installed ........................................................................................................................................... 120V

Recommended circuit and fuse/breaker size

..................................................................................................... 15A

Capacities:

Horizontal capacity:

Round at 90 degrees ........................................................................................................................................ 5 in.

Round at 45 degrees ........................................................................................................................................ 3 in.

Rectangle at 90 degrees ................................................................................. 5(H) x 5-3/4(W); and 2(H) x 6(W) in.

Rectangle at 45 degrees ............................................................................................................ 4-1/2(H) x 3(W) in.

Throat depth ........................................................................................................................................ 5 in. (127 mm)

Bow and blade:

Blade type (provided) ........................................................................................................................................ Raker

Blade size ..................................................................................................................................... 1/2 x 0.025 x 65 in.

Number of blade speeds ........................................................................................................................................... 3

Blade speeds ............................................................................................................................... 80, 120, 200 SFPM

Blade wheel diameter .................................................................................................................... 7-3/8 in. (187 mm)

Bed and vise:

Bed height from floor ................................................................................................................... 25-1/2 in. (648 mm)

Vise swivel ...................................................................................................................................................... 45 deg.

Main materials:

Bed ......................................................................................................................................cast iron, ground surface

Bow ............................................................................................................................................................... cast iron

Stand .................................................................................................................................................................. steel

Blade drive system .................................................. steel, heat-treated worm driving a bronze worm gear in oil bath

Side blade guides ..................................................................................... ball bearings mounted on eccentric shafts

Rear blade guides ................................................................................................................................... ball bearings

Band wheels ..................................................................................................................................... flanged cast iron

Dimensions:

Vertical table plate dimensions ............................................................................. 9-5/8 x 9-1/2 in. (244.5 x 241 mm)

Floor space required .......................................................................................... 16-1/4 x 42-1/2 in. (413 x 1080 mm)

Overall dimensions, assembled machine ................................... L37 x W17.72 x H41.34 in. (940 x 450 x 1050 mm)

Overall dimensions, shipping carton ........................................ L38.78 x W13.98 x H17.80 in. (985 x 355 x 452 mm)

Weights:

Net weight (approx.) .......................................................................................................................... 115 lbs. (52 kg)

Shipping weight (approx.) ............................................................................................................. 143.30 lbs. (65 kg)

Subject to local/national electrical codes.

The specifications in this manual were current at time of publication, but because of our policy of continuous

improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring

obligations.
