9
Contents of the Shipping Container
1. Head Assembly
1. Table
1. Column and Bracket Assembly
1. Base
1. Owner’s Manual
1. Warranty Registration Card
1. Chuck and Chuck Key
3. Downfeed Handle
1. Table Bracket Lock Handle
1. Table Bracket Raising Handle
4. M10 x 40 Hex Cap Bolts
1. Arbor
1. Drift Key
Tools Supplied for Assembly
1. 3mm Hex Wrench
1. 5mm Hex Wrench
Tools Required for Assembly
1. 17mm Box Wrench or a 6”-8” Adjustable
Wrench
, WARNING!
Read and understand all assembly
instructions before attempting assembly!
Failure to comply may cause serious injury!
Before Assembly
1. Remove the contents from the shipping
container.
2. Compare the contents of the shipping
container with the list found above. Report
any shortages or damage to your JET
distributor.
3. Clean all rust protected surfaces with
kerosene or a light solvent. Do not use
lacquer thinner, paint thinner, or gasoline.
These will damage plastic components and
painted surfaces.
