21
Wiring Diagram
JDP-20MF Electrical Schematic – 115V
WHITE
BLACK
BLACK
WHITE
GREEN
GREEN
GROUND
1
3
2
4
WHITE
BLACK
GREEN
ON / OFF SWITCH
LAMP SWITCH
BLACK
BLACK
BLACK
WHITE
LAMP
STARTING CAPACITOR
400MFD 125 VAC
JDP-20MF Electrical Schematic – 230V
GREEN
GROUND
WHITE
BLACK
GREEN
4
BLACK
WHITE
1
3 2
400MFD 125 VAC
WHITE
GREEN
BLACK
LAMP SWITCH
BLACK
BLACK
WHITE
BLACK
LAMP
ON / OFF SWITCH
STARTING CAPACITOR
