Uncrating
1. Remove contents from the shipping box.
2. Inspect contents for shipping damage and
report damage, if any, to your distributor.
3. Be sure to keep the box and packing
material should you need to pack the lathe
for moving.
4. Do not clean the lathe with anything other
than a damp cloth or a mild solvent. Use of
heavy solvents, paint thinner, gasoline, etc.
will damage painted surfaces.
Contents of the Shipping Carton:
1 - Lathe w/ motor and tailstock
1 - Tool rest
1 - Face plate
1 - Drift rod
1 - Live center
1 - Spur center
1 - Safety goggles
1 - Owner's manual
1 - Warranty card
Assembly
The JML-1014 is fully assembled and comes
ready to use right out of the box. However, it is
a good practice to thoroughly check the machine
for loose fasteners, handles, etc. before use.
Controls
Tailstock Handwheel (A, Fig. 1) - turn
clockwise to move tailstock spindle forward.
Turn counter-clockwise to retract tailstock
spindle.
Tailstock Spindle Lock (B, Fig. 1) - locks
tailstock spindle. Release to adjust with
handwheel.
Tailstock Lock (C, Fig. 1) - locks tailstock in
position on the bed. Release to move tailstock
assembly closer to or farther from the
headstock.
