6
4.0 Specifications
Table 1
Model number JWBS-14SFX
Stock numbers
Band Saw with Stand 714400K
Band Saw only 714401
Stand only 714402
Light kit (optional accessory) 714403
Motor and electricals
Motor type Totally-enclosed fan-cooled induction, capacitor run
Horsepower 1.75 HP (1.3 kW)
Motor phase Single
Motor voltage 115/230 V (prewired 115 V)
Cycle 60 Hz
Listed FLA (full load amps) 15 / 7.5A
Run capacitor
40μF 450VAC
Motor speed 1720 RPM
Starting current 63 / 34 A
Running current (no load) 7.1 / 3.6 A
Power transfer v-belt
On/off switch Industrial-style push button
Power cord and plug SJT 14AWGx3C, 6ft., 5-15P plug
Recommended circuit size
1
15 A
Sound emission without load
2
75 dB at 3 ft. (900mm) from blade
Capacities and speeds
Band saw nominal size 14 in. (355 mm)
Wheel diameter 14 in. (355 mm)
Resaw capacity (cutting height) 13 in. (330 mm)
Throat capacity 13-1/2 in. (345 mm)
Blade length 116-1/4 in. (2953 mm)
Minimum blade width 1/8 in. (3.175 mm)
Maximum blade width 1 in. (25.5 mm)
Blade speed 15.24 m/s (3000 FPM)
Wheel speed 765 RPM
Blade provided Hook type, 116.25” x 5/8” x 0.02” x 4 TPI
Main materials
Table Ground cast iron
Table insert Anodized aluminum
Trunnion Cast iron
Frame Steel
Stand Steel
Band wheels Cast iron
Tires Polyurethane
Blade guides Ball bearings, aluminum block
Resaw fence Extruded aluminum
Paint finish Powder coating
Door knobs Plastic
Dust collection
Dust port outside diameter 4 in. (100mm) x 2
Minimum extraction volume required 400 CFM
