7
5.0 Specifications
Table 1
Model number JWSS-18B
Stock numbers
Scroll saw only 727300B
Scroll saw with stand 727300K
Stand only 727300S
Motor and electricals
Motor type brushed DC
Horsepower 1/16 HP (50W)
Motor phase single
Motor voltage 120 V
Cycle 60 Hz
Listed FLA (full load amps) 1.3 A
Starting current 2 A
Running current (no load) 0.5 A
On/off switch rocker style
Power cord 18 AWG, 6 ft. (183 cm)
Power plug installed 15 A
Foot pedal cord (optional) 18 AWG, 7.2 ft. (220 cm)
Recommended circuit and fuse/breaker size
1
5-15P, 15A
Overload fuse 3.15A, 250V
Blade and capacities
Stroke 3/4 in. (18.6 mm)
Speed variable, 400 to 1550 stroke/min.
Throat capacity 18-1/2 in. (470 mm)
Blade type used plain-end (pinless) 5 in.
Blades included (5) reverse skip tooth
Maximum cutting depth 2 in. (51 mm)
Arm tilt 45 deg. right; 30 deg. left (45 deg. with removal of dust port)
Main materials
Body steel
Main table steel
Trunnion steel
Arm steel, plastic cover
Dimensions
Optional stand footprint (LxW) 28 x 25-1/2 in. (711 x 648 mm)
Overall dimensions – saw only (LxWxH) 30.7 x 15.7 x 17.3 in. (780 x 400 x 440 mm)
Overall dimensions – saw on stand (LxWxH) 33 x 25-1/2 x 48 in. (838 x 648 x 1219 mm)
Shipping dimensions – saw only 33.2” x 18.9 x 19" (845mm x 480mm x 485mm)
Dust collection
Dust port diameter inside 2.28 in. (58mm); outside 2.5 in. (63mm)
Recommended dust extraction volume 300–350 CFM (8.5–10 CMM)
Weights
Net weight, saw only 54 lbs ( 24.5 kg)
Shipping weight, saw only 62.5 lbs ( 28.5 kg)
Net weight, optional stand only 21.5 lbs (9.8 kg)
1
subject to local/national electrical codes.
L = length; W = width; H = height CFM=cubic feet per minute
Specifications in this manual were current at time of publication, but because of our policy of continuous improvement,
JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.
