IMPORTANT NOTES:
• The GPS does not control the speed of the engine. You must use the Airspeed
Sensor for this function.
• Range check you R/C system after installation of the GPS. You must get the
same range with or without the GPS connected.
The GPS Menu
If GPS is enabled in the Limits Menu and the optional GPS receiver/antenna is
installed, the following functions are available. All distance measurements are in meters:
Value Explanation
GPS-Speed
GPS-Alti
Real time ground speed of the model.
Real time altitude above sea level of the model.
GpsCource
Sat
Fix
Angle the plane is currently flying at (0-360 degrees).
Number of satellites in view of the receiver.
Displays if the receiver has a fix on the satellites.
• NV = Not valid.
• OK = Fix on satellites. Data valid.
Lati
Long
Latitude of the model.
Longitude of the model.
GPS MaxSpd
GPS AvgSpd
Maximum ground speed of the model.
Average ground speed of the model.
GPS MaxAlt
GPS MinAlt
Maximum altitude above sea level the model achieved.
Minimum altitude above sea level the model achieved.
GP-Dist.
MaxH
R
Total linear distance the model traveled from the takeoff point.
Maximum height achieved above take-off point.
Radial distance model is currently from the takeoff point.
GPS-Time (UTC)
Current time.
