JETI model DUPLEX REX3 User Manual

COMPLEX RADIO CONTROL SYSTEM
* xternal ower onnector -the receiver has a power supply cable with an E P C
MPX connector
* - lim design, slim receiver for using in narrow fuselage S S
Basic data
REX3
REX6
REX7
REX7S*
REX9S*
REX10
REX12*
Dimension [mm]
40x22x7
38x25x11
42x28x11
60x16x13
60x16x13
51x28x11
51x28x11
Weight [g]
7
11
13
13
13
16
24
Antenna lenght [mm]
2x100
2x100
2x200
2x200
2x200
2x200
2x400
Num. of output ch.
3
6
7
7
9
10
12
Temp. range [°C]
-10 to +85
-10 to +85
-10 to +85
-10 to +85
-10 to +85
-10 to +85
-10 to +85
Supply voltage [V]
3.5 – 8.4
3.5 – 8.4
3.5 – 8.4
3.5 – 8.4
3.5 – 8.4
3.5 – 8.4
3.5 – 8.4
Average current [mA]
70
75
75
75
75
75
75
Real time transmission
of telemetry data
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Programming
DC/DS
JETIBOX
DC/DS
JETIBOX
DC/DS
JETIBOX
DC/DS
JETIBOX
JETIBOX
DC/DS
DC/DS
JETIBOX
DC/DS
JETIBOX
Support satellite
receiver (Rsat)
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Power output [dBm]
15
15
15
15
15
15
15
Receiver sens. [dBm]
-106
-106
-106
-106
-106
-106
-106
Frequency [MHz]
2400-2483
2400-2483
2400-2483
2400-2483
2400-2483
2400-2483
2400-2483
2.1 Receivers 2.4 GHz
EN
2 Technical data
22

JETI model DUPLEX REX3 Specifications
