JETI model DUPLEX REX3 User Manual

COMPLEX RADIO CONTROL SYSTEM
2.1 Receivers 900 MHz
Basic data
Rsat 900
Dimensions [mm]
40x22x7
40x22x7
Weight [g]
11
11
Antenna lenght [mm]
2x300
2x260
Number of output channels
3
3
Temperature range [°C]
-10 do+85
-10 do+85
Supply voltage [V]
3.5 – 8.4
3.5 – 8.4
Average current [mA]
70
50
Real time transmission of telemetry data
Yes
Yes
Programming
DC/DS/JETIBOX
DC/DS
Power output [dBm]
14
14
Receiver sensitivity [dBm]
-110
-120
Frequency [Mhz]
863 - 870 (EU)
902 - 928 (US)
918 - 926 (AU)
863 - 870 (EU)
918 - 926 (AU)
902 - 928 (US)
EN
Note:
RSAT900 and RSAT900NG satellite receivers are not compatible
with all transmitters. The RSAT900NG satellite receiver is
compatible with DUPLEX DS 12, DUPLEX DC/DS 16II and
DUPLEX DC/DS 24II transmitters. The RSAT 900 satellite receiver is
intended for first generation DUPLEX DC/DS 24 transmitters.
23
