Jetline 9700W - Calibration Limits and Settings

Page 34
HI LIMIT
Hi Lmt is the upper limit of the wire speed. Minimum value is
0.000 and Maximum value is 3000.000.
HI OUT
Hi Out is the voltage that is put out of the 9700-10 board to reach
the upper limit of the travel motor. Minimum value is 0.000 and
Maximum value is 10.000.
HI IN
Hi In is the voltage of the feedback from the motor when running
at the high limit. Minimum value is 0.000 and Maximum value is
100.000.
LOW LIMIT
Low Lmt is the lower limit of the wire feed speed. Minimum value
is 0.000 and Maximum value is 999.999.
LOW OUT
Low Out is the voltage that is put out of the 9700-10 board to
reach the lower limit of travel motor. Minimum value is -1.000 and
Maximum value is 10.000.
CALIB
ACTUAL
200.000
8.532
HI LMT
HI OUT
DISPLAY
CALIB
200.000
8.532
18.092
HI LMT
HI OUT
HI IN
CALIB
8.532
18.092
4.000
HI OUT
HI IN
LOW LMT
CALIB
18.092
4.000
0.421
LOW LMT
LOW OUT
HI IN
CALIB
4.000
0.421
0.385
LOW LMT
LOW OUT
LOW IN
