3. SECURE THE LATCH WITH THE LOCKING RING:
ROTATE THE RING CLOCKWISE AROUND THE STEM
UNTIL THE TAB ON THE RING SLIDES INTO THE TAB
SLOT ON THE LATCH.
4. CHECK THAT THE LATCH IS SECURED BY ENSURING
THAT IT CANNOT BE PULLED OPEN.
IMPORTANT: NEVER RIDE THE BOLT WITHOUT
THE FOLDING LATCH CLOSED AND SECURED BY THE
LOCKING RING.
LOCKING RING
LOCKING RING TAB
3
4
