Jetson Core - Page 34

32
2. RAISE OR LOWER THE SEAT TO THE DESIRED POSITION. IMPORTANT: DO NOT TO RAISE THE SEAT HIGH ENOUGH THAT
THE“MINIMUM INSERTION” MARK COMES INTO VIEW ABOVE THE CLAMP. (IF THE SEAT CLAMP IS TOO TIGHT FOR THE POST
TO SLIDE UP AND DOWN EASILY, WIDEN THE CLAMP OPENING BY TURNING THE CLAMP KNOB COUNTERCLOCKWISE.)
3. WHILE HOLDING THE SEAT IN PLACE, CLOSE THE SEAT LATCH AND, IF NECESSARY, RE-TIGHTEN THE CLAMP KNOB BY
TURNING IT CLOCKWISE. CLOSE THE CLAMP LATCH.
SEAT
KNOB
LATCH
