2.2 Charging the Battery
- CHARGING
- CHARGING COMPLETE
CHARGING INDICATOR LIGHT ON THE CHARGER:
CHARGER
CHARGING CABLE
IN-FRAME CHARGING PORT
BATTERY REMOVED FROM FRAME
CHARGING PORT
CHARGING PORT COVER
IT CAN TAKE ABOUT 5 HOURS TO BRING A DEPLETED
BATTERY TO FULL CHARGE.
THE BATTERY CAN BE CHARGED WHEN IT IS SECURED IN THE
FRAME OR REMOVED FROM THE FRAME. (SEE SECTION 3.1
FOR REMOVAL.)
1. CONNECT THE CHARGING CABLE WITH THE CHARGER.
2. PULL OPEN THE CHARGING PORT COVER ON THE BIKE
FRAME, IF CHARGING THE BATTERY WHILE IT'S IN
THE FRAME.
3. PLUG THE CHARGING CABLE INTO THE WALL, AND THEN
PLUG THE CHARGER INTO THE CHARGING PORT.
4. WHEN THE INDICATOR LIGHT ON THE CHARGER TURNS
FROM RED TO GREEN, YOUR BATTERY HAS REACHED FULL
CHARGE. REMOVE THE CHARGER FROM THE CHARGING
PORT AND UNPLUG THE CABLE FROM THE WALL OUTLET.
5. CLOSE THE CHARGING PORT COVER, IF CHARGING THE
BATTERY WHILE IT'S IN THE FRAME.
CHARGING INDICATOR LIGHT
