4. LIFT THE HANDLEBAR ONTO THE CLAMP BASE AND POSITION IT SUCH THAT IT IS:
• NESTLED INTO THE CURVE OF THE CLAMP.
• ORIENTED WITH THE LCD SCREEN ON THE LEFT-HAND SIDE OF THE HANDLEBAR.
• CENTERED AND BALANCED IN THE CLAMP.
• POSITIONED SUCH THAT ALL HANDLEBAR ELEMENTS ARE VISIBLE TO AND EASY TO REACH BY THE RIDER.
HANDLEBAR
CLAMP BASE LCD SCREEN
