Jetson Horizon User Manual

10
• PRODUCT DIMENSIONS: 43.3″ L X 23.6″ W X 27.5″ H
• HANDLEBAR HEIGHT: 31.5″
• SEAT HEIGHT: 21″
• PRODUCT WEIGHT: 39.4 LBS
• TIRE SIZE: 12″
• BRAKE TYPE: HANDBRAKE
• WEIGHT LIMIT: 140 LBS
• RECOMMENDED AGE: 13+
FOR SAFE AND COMFORTABLE RIDING, THERE SHOULD
BE A CLEARANCE OF AT LEAST 1  3 INCHES BETWEEN
THE CROTCH AND THE TOP TUBE OF THE BIKE FRAME
WHEN THE RIDER STRADDLES THE BIKE WITH BOTH
FEET FLAT ON THE GROUND.
1-3
inches
1.2 Specs & Features
1.3 Rider Suitability
• MAX SPEED: 15.5 MPH
• MAX RUN TIME: 30 MINS.
• CHARGING TIME: ABOUT 4 HOURS
• RECOMMENDED TIRE PRESSURE: 36  43 PSI
• WATER RESISTANCE RATING: IPX4
• UL CERTIFICATION: UL2271
• CHARGER: UL LISTED, 42V 1.0A

Jetson Horizon Specifications

General

Motor Power	350W
Battery Capacity	36V 7.8Ah
Max Speed	25 km/h
Range	30 km
Max Load	100 kg
Brake Type	Disc Brake
Suspension	Front Suspension
