3 - Machine presentation
3.1 - Available versions
The Grass Head JF 1300 S2 can be coupled in the following forage harvesters:
Ÿ JF 92 Z10, actuated via cardan shaft;
Ÿ JF 92 Z10, drive-through pulley and belts;
Ÿ JF 92 Z6, drive-through pulley and belts;
Ÿ JF C120, C60 e C40, actuated via cardan shaft;
Ÿ JF C120, C60 e C40 drive-through pulley and belts.
Notice that this choice must be made at the moment of the purchase of the JF 1300 S2
platform. To modify it’s version (if possible), please, contact our Post Sale Department.
3.2 - Components identification
1- Cut discs;
2- Protection cover;
3- Diverters;
4- Lateral structure (arm);
5- Protection covers;
6- Cardan shaft;
7- PTO cardan shaft;
8- Gearbox transmission;
9- Pulley transmission.
11
OPERATION TECHNICAL MANUAL - JF 1300 GRASS HEAD SERIES 2
English
