3.3 - Running
Whenever the terms “rigth” and “left” are used, it is considered the tractor’s
operating cab as reference point.
The Grass Head JF 1300 S2 was developed to harvest and collect grass.
While the machine goes, the grass passes thought the protective cover (1), and is cut by the
cutting discs (2), and immediately to the rolls of the harvester forage harvesters (3).
From this point of the functions ate performed by harvesting forage harvester attached to the
platform which is coupled, as described in it’s manual.
1
2
3
13
OPERATION TECHNICAL MANUAL - JF 1300 GRASS HEAD SERIES 2
English
