34
Driving Cardan
Lubricate using a brush
Manual lubrication
You should lubricate the cutting gears (1) every 50
working hours or weekly, using a brush.
To do it: pen cover (2) by loosening bolts (5) using a
wrench according to the table of sub-item 12.1.
Note: Use the same grease specified in the previous
page.
Note:
To lubricate the tail shaft with a brush, the
machine should be turned off and the shaft
uncoupled.
2
1
