26
Parameter
Model
JSI-5000TL
JSI-5000TL-S
JSI-6000TL
JSI-6000TL-S
Inpu t Data
Max. DC power 5200W 6250W
Max. DC voltage 550V 550V
MPPT operating
voltage range
100V-500V 100V-500V
Number of
para ll el inpu t s
33
Numbe r of MPP
trac ke r s
11
Max. input current
(tot al )
22.5 A 27.5 A
Output Data
Nominal AC output
powe r
4600 W 6000 W
Max. AC power 5000W 6000W
Max. output current 24A 31.2A
AC grid volt age range 206~270Vac 206~270Vac
AC grid freq uency
range
49.25~50.75Hz 49.25~50.75Hz
Power fact or
(
cos φ
)
>0.99 >0.99
THDI(at nominal
outp ut po wer )
<3% <3%
AC connection Single phase Single phase
Max. efficiency 97.6% 97.6%
Euro efficiency 97% 97.1%
MPPT ef fi ci en cy 99.6 % 99.6 %
Gene ra l Data
Dimensions (W /H/D)
in mm
345/ 152 / 505 345 /162 / 573
Weight
19Kg 24K g
Operating
temperature range
–25 °C ~+60 °C –25 °C ~+60 °C
