USR-TCP232-410S User Manual
26 / 46
4.1.14 Webpage Port
410S has built-in webpage server and the port is 80. Also the port can be revised and visit the web via
revised port.
4.1.15 Revise MAC
User can check software’s MAC address. 410S’s MAC is Globally Unique. Also it support customized
MAC.
4.1.16 Firmware Upgrade
410S’ firmware upgrade is fulfilled via network. For details, please refer to Chapter 5.1 configure
parameter with configuration software.
4.1.17 Customized Webpage
User can make revise as logo/name on the basis of 410S webpage.
1. Download UpgradeHtml.exe. The link is
http://www.usriot.com/e45-m4-seriesk3-self-defined-webpage/
3. Open “UpgradeHtml.exe”, set 410S’ IP, Select product M4 and upload revised webpage file.
Then upgrade.
Customized Webpage Upgrade
