USR-TCP232-410S User Manual
7 / 46
USR-TCP232-410S is to transmit transparently between TCP/UDP data packet and RS232/RS485
interface. It carries ARM Processor, low power, fast speed, high stability.
1. Multiple indicator lights for convenient debugging
2. Power-line terminal for industrial application
3. ARM kernel, Industrial operating temperature range and reliable TCP/IP protocol stack
4. Auto-MDI/MDIX,RJ45 port with 10/100Mbps
5. TCP Server,TCP Client,UDP,UDP Server and HTTPD Client work mode
3. Two ports can work independently at the same time
4. Distinguish connected serial ports via port#
5. Support virtual serial port and provide corresponding software USR-VCOM
6. Serial baud rate from 600bps to 230.4K bps; Check bit of None,Odd,Even,Mark and Space
7. Support static IP, DHCP and search devices within network through UDP broadcast.
8. Provide serial and network setting protocol, key codes explanation
9. Provide PC TCP/IP SOCKET programming example,VB,C++,Delphi,Android,IOS
10. Built-in webpage; also can customize webpage for VIP customers
11. Reload button,one key to restore default settings
12. RJ45 with Link/Data indicator light,built-in isolation transformer and 2 KV electromagnetic isolation
13. The global unique MAC address bought from IEEE, also user can define MAC address
14. Support upgrade firmware via network
16. Support web port revise (80 by default)
17. Support keepalive, detect dead links and reconnect rapidly
18. Support account and password, used to page log in and network settings safely
19. Support one channel Websocket,realize bidirectional transparent transmission between webpage
and serial.
20. Support Modbus RTU to Modbus TCP
21. Support UDP broadcast function, send and receive data from all IP in the network
