USR-TCP232-410S User Manual
33 / 46
4.1.1.3 Commands’ Return Content
1. Return results of search command
Return command:
Device MAC(High in front)
D0 07: device version# (low in
front)
12 34: encrypted version
55 53 52 2D 54 43
50 32 33 32 2D 35
30 30 00 00
Example:
Return results of search command(36 bytes)
FF 24 01 00 4B C0 A8 00 4D D8 B0 4C 00 04 C9 DD 07 01 00 55 53 52 2D 54 43 50 32 33 32 2D 34 30
31 00 00 EF
The method of the check is as follow:
0xEF = 00 - FF - 24 - 01 - 00 - 4B - ... - 31 - 00 - 00
2. Return results of reset command
Response(4 bytes): FF 01 02 4B, if user name and password are right, 4B = 'K'
FF 01 02 45, if user name and password are wrong, 45 = 'E'
3. Return results of read command
Description：
Return all parameter of 410S network. 193 bytes in total, no parity, no protocol, return parameter directly.
Returned content: 193 (basic parameter+serial parameter+serial parameter)
