Jinan USR IOT Technology USR-TCP232-T User Manual

S erial to Ethernet module USR-TCP232-T24 series http://en.usr.cn
Jinan USR IOT Technology Limited Page 19 of 53 tec@usr.cn
2.5
2.5
2.5
2.5 USR-TCP232-200
USR-TCP232-200
USR-TCP232-200
USR-TCP232-200
USR-TCP232-2 00 Model RS232 level, the 2KV electromagnetic isolation RJ45 interface, 5.5 * 2.1
standard power supply or terminal power supply serial server .
2.5.1
2.5.1
2.5.1
2.5.1 Technical
Technical
Technical
Technical Specifications
Specifications
Specifications
Specifications
Ma
Ma
Ma
Ma jor
jor
jor
jor characteristic
characteristic
characteristic
characteristic P
P
P
P arameter
arameter
arameter
arameter
Power Supply DC 5V @ 1A power adapter
Serial port level RS232
Network interface RJ45 ports with 2KV electromagnetic isolation
Physical Siz e :
PCB size : 60*40mm(L*W)
P roduct size : 70 × 40 × 25 mm （ L * W * H ）
Temperature and
humidity range
Operating temperature: -25 to 75 ° C
Storage temperature: -40 to 80 ° C
Storage humidity: 5% to 95% RH
Warranty period 2 years
