JLA D120 - Mechanical Specifications

6 JLA Limited 113375-16
MAXIMUM CAPACITY (DRY WEIGHT) 120 lb
54.43 kg
TUMBLER DIAMETER 44-1/8”
112.09 cm
TUMBLER DEPTH 40-9/16”
103.02 cm
TUMBLER VOLUME 35.90 cu ft
1,016.57 L
TUMBLER / DRIVE MOTOR 1 hp
0.75 kW
BLOWER / FAN MOTOR 3 hp
2.24 kW
DOOR OPENING (DIAMETER) 31-3/8”
79.71 cm
DOOR SILL HEIGHT 26-5/8”
67.64 cm
WATER CONNECTION 3/4”-11.5 NH
(North America)
3/4” B.S.P.T. (Outside North America)
DRYERS PER 20’/40’ CONTAINER 3 / 7
DRYERS PER 48’/53’ TRUCK 9 / 10
VOLTAGE AVAILABLE 208-480v 3ø 3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 1,370 lb
621.42 kg
APPROXIMATE SHIPPING WEIGHT 1,430 lb
648.64 kg
AIRFLOW
60 Hz
2,800 cfm
79.29 cmm
50 Hz
2,333 cfm
66.06 cmm
HEAT INPUT 375,000 Btu/hr
94,498 kcal/hr
EXHAUST CONNECTION (DIAMETER) 16 ”
40.64 cm
COMPRESSED AIR CONNECTION 1/4” Qui ck Connection
COMPRESSED AIR VOLUME 2.50 cfh
0.07 cmh
INLET PIPE CONNECTION 1” F.B.S.P.T.
1” B.S.P.T.
(CE and Australia Only)
VOLTAGE AVAILABLE 208-480v 3ø 3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 1,370 lb
621.42 kg
APPROXIMATE SHIPPING WEIGHT 1,430 lb
648.64 kg
AIRFLOW
60 Hz
2,800 cfm
79.29 cmm
50 Hz
2,333 cfm
66.06 cmm
EXHAUST CONNECTION (DIAMETER) 16 ”
40.64 cm
COMPRESSED AIR CONNECTION 1/4” Qui ck Connection
COMPRESSED AIR VOLUME 2.50 cfh
0.07 cmh
OVEN SIZE
kW Btu/hr
kcal/hr
72 245,729
61,923
VOLTAGE AVAILABLE 208-480v 3ø 3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 1,450 lb
657.71 kg
APPROXIMATE SHIPPING WEIGHT 1,500 lb
680.39 kg
AIRFLOW
60 Hz
2,800 cfm
79.29 cmm
50 Hz
2,333 cfm
66.07 cmm
STEAM CONSUMPTION 450 lb/hr
204.12 kg/hr
OPERATING STEAM PRESSURE 125 psi max
8.62 bar
EXHAUST CONNECTION (DIAMETER) 16 ”
40.64 cm
COMPRESSED AIR CONNECTION 1/4” Qui ck Connection
COMPRESSED AIR VOLUME 3.25 cfh
0.09 cmh
BOILER HORSEPOWER (NORMAL LOAD) 13 Bhp
SUPPLY CONNECTION (1) 1-1/4” N.P.T.
(Female)
RETURN CONNECTION (1) 1-1/4” N.P.T. (Female)
ELECTRIC
Mechanical Specifications _______________________________________________________
GAS
STEAM
IMPORTANT: Dryer requires a clean, dry and regulated 80 PSI +/- 10 PSI (5.51 bar +/- 0.68 bar) air supply.
NOTE:
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
Shaded areas are stated in metric equivalents 1/9/15
