IMPORTANT
You must disconnect and lock out the electric
supply and the gas supply or the steam supply
before any covers or guards are removed from
the machine to allow access for cleaning,
adjusting, installation, or testing of any equipment
per OSHA (Occupational Safety and Health
Administration) standards.
Please observe all safety precautions displayed
on the equipment and/or specified in the
installation manual included with the dryer.
CAUTION
Dryer(s) should never be left unattended while in
operation.
“Caution: Label all wires prior to disconnection
when servicing controls. Wiring errors can cause
improper operation.”
«Attention: Lor des opérations d’entretien des
commandes étiqueter tous filsnt de les
déconnecter. Toute erreur de câblage peut étre
une source de danger et de panne.»
WARNING
Children should not be allowed to play on or near
the dryer(s). Children should be supervised if near
dryer(s) in Operation.
Under no circumstances should the dryer door
switch, lint drawer switch, or heat safety circuit
ever be disabled.
The dryer must never be operated with any of the
back guards, outer tops, or service panels
removed. Personal injury or fire could result.
The dryer must never be operated without the lint
filter/screen in place, even if an external lint
collection system is used.
FOR YOUR SAFETY
Do not dry mop heads in the dryer. Do not use
dryer in the presence of dry cleaning fumes.
Dryers must not be installed or stored in an
area where it will be exposed to water and/or
weather.
The wiring diagram for the dryer is located in
the front electrical control box area.
Table of Contents
Safety Precautions ................................4
Specifications ........................................ 5
Installation Procedures .........................7
Unpacking/Setting Up ................................................. 7
Location Requirements ............................................... 7
Dryer Enclosure Requirements....................................7
Fresh Air Supply Requirements................................... 8
Exhaust Requirements................................................ 8
Electrical Information ................................................ 11
Gas Information ........................................................ 14
Steam Information ..................................................... 16
Water Information ..................................................... 19
Preparation for Operation/Start-Up ............................. 21
Preoperational Tests ................................................. 22
Preoperational Instructions........................................ 22
Shutdown Instructions............................................... 23
Service/Parts Information ..................24
Service ..................................................................... 24
Parts ........................................................................ 24
Warranty Information ..........................24
Returning Warranty Cards......................................... 24
Warranty .................................................................. 24
Routine Maintenance...........................24
Cleaning ................................................................... 24
Adjustments ............................................................. 25
Lubrication ............................................................... 25
Lint Drawer Removal ................................................. 25
Data Label Information .......................25
Procedure for Functional Check
of Replacement Components .............26
Manual Reset Burner Hi-Limit
Instructions ..........................................27
Phase 7 .................................................................... 27
Dual Timer ................................................................ 27
