113242-3 5
Specifications _______________________
!
Shaded areas are stated in metric equivalents 2/19/04
* Reversing dryer available with 3-phase (3ø) 1/2 hp (0.373 kW) motors standard.
** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be provided with clean, dry and
regulated 80 psi ± 10 psi (5.51 bar ± 0.68 bar) air supply.
Note
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
GasElectricSteam**
MAXIMUM CAPACITY (DRY WEIGHT) 30 lbs
13.6 kg
TUMBLER DIAMETER 32-3/4”
83.2 cm
TUMBLER DEPTH 25-5/8”
65.1 cm
TUMBLER VOLUME 12.5 cu ft
0.354 cu m
TUMBLER/DRIVE MOTOR* 1/2 hp
0.373 kW
DOOR OPENING (DIAMETER) 21-1/2”
54.61 cm
AIRFLOW 60 HZ 460 cfm
13 cmm
AIRFLOW 50 HZ
382 cfm
11 cmm
EXHAUST CONNECTION (DIAMETER) 8”
20.32 cm
WATER CONNECTION 3/4” M.N.P.T.
DRYERS PER 20’/40’ CONTAINER 12/24
DRYERS PER 48’/53’ TRUCK 30/32
VOLTAGE AVAILABLE 120-480v 1, 3 ø 2, 3, 4 w 50/60 Hz
APPROX. NET WEIGHT 517 lbs
234.5 kg
APPROX. SHIPPING WEIGHT 552 lbs
250.38 kg
HEAT INPUT 95,000 Btu/hr
kcal/hr
INLET PIPE CONNECTION 1/2” F.B.S.P.T.
VOLTAGE AVAILABLE 208-460v 1, 3 ø 2, 3, 4 w 50/60 Hz
OVEN SIZE
kW Btu/hr
kcal/hr
20 68,200
17,200
22 75,000
18,900
24 81,900
20,600
25.2 85,900
21,700
VOLTAGE AVAILABLE 120-480v 1, 3 ø 2, 3, 4 w 50/60 Hz
APPROX. NET WEIGHT 577 lbs
261.72 kg
APPROX. SHIPPING WEIGHT 612 lbs
277.59 kg
STEAM CONSUMPTION 104 lbs/hr
47.17 kg/hr
OPERATING STEAM PRESSURE 125 psi max
8.6 bar
COMPRESSED AIR CONNECTION 1/8” F.N.P.T.
COMPRESSED AIR VOLUME 0.5 cfh
0.014 cmh
BOILER HP (NORMAL LOAD) 3
SUPPLY CONNECTION 1” F.N.P.T.
RETURN CONNECTION 1” F.N.P.T.
