SECTION 1 - SPECIFICATIONS
3120855 – JLG Sizzor – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
Hydraulic Oil Tank
1932E2
11.4 liters at full mark on tank
9.5 liters at add mark on tank
2032E2/2632E2/2646E2/3246E2
14.8 liters at full mark on tank
12.9 liters at add mark on tank
Hydraulic System (Including Tank)
1932E2 - Approximately 15.0 liters
2032E2/2632E2/2646E2/3246E2 - Approximately 19.0
liters
1.2 COMPONENT DATA
Hydraulic Pump/Electric Motor Assembly
24 Volts DC motor w/Single section gear pump
1932E2 8.5 lpm
2032E2/2632E2/2646E2/3246E2 -11.4 lpm
Battery Charger
20 Amp SCR
120/240 Volts AC - 50 Hz input
24 Volts DC - 20 Amp output w/auto timer
Batteries (4)
1932E2/2032E2/2646E2 - 6 Volt, 220 Amp Hour
2632E2/3246E2 - 6 Volt, 245 Amp Hour
Steer/Drive System
Tires -1932E2
Standard - 12.5 x 4 - Solid, Non-Marking, Rib
Optional - 12.5x4 - Solid, Rib
Tires - 2032E2/2632E2/2646E2/3246E2
Standard - 16.00 x 5.00 - Solid, Non-Marking
Optional -16.00 x 5.00 - Solid, Rib
Parking Brake ( rear dual wheel) - Single cylinder, spring
applied, hydraulically released.
Drive Motors
1932E2 - 126 cm3 displacement
2032E2 - 229.4 cm3 displacement
2632E2 - 310.3 cm3 displacement
2646E2 - 265.5 cm3 displacement
3246E2 - 294 cm3 displacement
Hydraulic Filter - Inline
Return - Bypass Type
10 Microns Nominal
Platform Size
1932E2 - 0.8 m x 1.6 m
2032E2/2632E2 - 0.8 m x 2.1 m
2646E2/3246E2 - 1.1 m x 2.1 m
1.3 PERFORMANCE DATA
Travel Speed
1932E2
Low Speed - 2.1 kmh
Elevated Speed -1.1 kmh
Maximum Speed - 4.0 kmh
2032E2
Low Speed - 2.1 kmh
Elevated Speed - 1.1 kmh
Maximum Speed - 4.2 kmh
2632E2/2646E2
Low Speed - 2.1 kmh
Elevated Speed - 1.1 kmh
Maximum Speed - 3.6 kmh
3246E2
Low Speed - 2.1 kmh
Elevated Speed - 0.8 kmh
Maximum Speed - 3.2 kmh
