SECTION 3 - MACHINE OPERATION
3121740 3-3
1. Mast
2. Platform
3. Platform Entry Gates
4. Flywheel and Handle
5. Tool Tray
6. Manual Holder
7. Emergency Lowering Tool
8. Front Casters with Manual Brake
9. Fold-Down Platform Step
10. Fork Lift Pockets
11. Rear Wheels (Auto-Locking)
12. Indicator Bubble Level
Figure 3-2. Machine Component Locations(EcoLift 70)
