SECTION 3 - MACHINE OPERATION
3-2 3121740
3.3 MACHINE COMPONENT LOCATIONS
1. Mast Assembly
2. Platform
3. Platform Entry Gates
4. Flywheel and Handle
5. Tool Tray
6. Manual Holder
7. Emergency Lowering Tool
8. Front Caster
9. Front Foot Pads
10. Fork Lift Pockets
11. Rear Wheels (Auto-Locking)
12. Indicator Bubble Level
Figure 3-1. Machine Component Locations(EcoLift 50)
