8.3 System parameter query and setting
8.3.1 Query information item description
The query information items include main interface information, operation
information, basic information, water pump information, statistical information,
and fault information.
All query information items can be queried on the LCD display interface.
“Figure 8-2 LCD menu block diagram 1” lists the locations where all queried
information items are located.
The following describes the operation information, basic information, pump
information, statistical information, and fault information.
8.3.1.1 operation information
The items in the operation information show the current operation information
of the inverter. The following table explains each item in detail.
Figure8-3 The meaning of main interface parameters
RunInfo
Introduction
Vdc
Inverter input voltage (V).
Ipv
Inverter input current (A).
Ppv
Inverter input power (W).
Vgrid
Inverter current Grid input voltage (V)
Pgrid
Inverter current Grid input power (W)
State_AC
Inverter current Grid input situation
Fout
Inverter output current frequency (Hz).
Vuout
Inverter output U phase voltage (V)
Vvout
Inverter output V phase voltage (V)
Vwout
Inverter output W phase voltage (V)
Iuout
Inverter output U phase current (A).
