14
Joerns® Bed Frames
EasyCare®
©2023 Joerns Healthcare • 6110444 RevA • 000547
To Remove Actuator
Recommended Tools: Screwdriver, Hammer,
Masking Tape, Zip Ties
1. Identify the actuator to be replaced.
2. Tip the bed on its side to replace high/low actuator(s).
3. Unplug the actuator cord.
4. The actuator is held in place by two pins. Use a
screwdriver to remove the lock ring on each pin.
5. Slide the pins out of holes. If necessary, use the
hammer to tap out the pins.
6. You may now replace the actuator(s).
7. To reassemble the bed, reverse the previous steps,
making note of the following two important items:
• Assemble the pin and lock rings as
originally installed.
• Zip-ties should be replaced, with cords returned
to their original position and routing direction to
the control box.
To Remove AC Power Cable
Recommended Tools: Small Screwdriver, Masking
Tape, Zip Ties, 5/16" Nut Driver
1. Raise the bed so that there is about 27 inches
of clearance between the oor and the mattress
support platform of bed.
2. Unplug the power cable from the outlet.
3. Cut the zip-ties that hold the power cable to the
frame. Tape the remaining cables in their original
position. It is very important to keep the actuator
cables routed along the frame in their original
factory-installed positions. If this step is not followed,
damage to cables or electric shock may result.
4. Detach the ground wire from the bed frame
if equipped.
Warning: Possible Shock Hazard. Injury may result
from improper power cable routing. Always follow
proper factory-installed routing conguration. Be sure
to check condition of the power cable on a regular
basis. Do not use damaged or frayed power cables.
5. Using a small screwdriver, alternately depress the
small red latch tabs above and below AC receptacle
on the control box. Simultaneously, pull gently
outward on the power cable where it connects to
the control box, until the plug comes out.
6. Plug the replacement cable into the control box
until it latches. Attach the ground wire to the bed
frame.
7. Re-route the power cable along the frame in the
same position as the original routing.
8. Replace zip-ties along with cables in their original
position and routing to the control box. If this step
is not followed, damage to the cables or electric
shock may result.
