Jofemar Vision ES-PLUS - Volume and Weight

Vision Es-Plus // Vending
MNP141GBV00 Date: 2011/04/29 Rev. 0 PAGE 11 OF 24
These machines are fitted with holes and
supplied with an anchoring kit (fig. 9) that
can be used to anchor the machine to the
floor (fig. 10) or to the wall (fig. 11) for
greater stability and support and to
prevent thefts.
Fig. 09
Fig. 10 Fig. 11
3.2. Volume and weight
Dimensions Height (H) Width (W) Depth (D) Weight
Vision Es -Plus (with cooling unit)
1.825 mm
(71.850”)
800 mm
(31.496”)
1010 mm
(39.763”)
306 Kg
671 lb
Vision Es -Plus (without cooling unit)
1.825 mm
(71.850”)
800 mm
(31.496”)
975 mm
(39.763”)
726 Kg
1597.2 lb
* The weight of the machine is for with a 5 tray configuration.
