Jofemar Vision ES-PLUS - Description of Components

Vision Es-Plus // Vending
MNP141GBV00 Date: 2011/04/29 Rev. 0 PAGE 5 OF 24
WITH COOLING UNIT WITHOUT COOLING UNIT
MAIN SWITCH POSITION AND RS-232 CONNECTOR
WITH COOLING UNIT WITHOUT COOLING UNIT
Posición Descripción Posición Descripción
A Door I Door microswitch
B Lock J Electronics support
C Product delivery opening K RS-232 connection
D Safety glass L Fuse/Fuse holder
E Iluminación Leds M Main switch
F Cabinet N Cooling unit
G Trays and channels Ñ Turbine
H Elevator O Photocell scanning assembly
M M K K
N
Ñ
O
