John Bean EELR529A - Page 15

- 15 -
Figure 9 - Cable Route
Inside Deck and Cross Beam
Cable 2
Cable 4
Cable 1
Cable 3
Cable 1
Cable 3
Cable 3
Cable 2
Cable 4
Figure 10 - Cable Pulley
No need to
unscrew this bolt
No need to fully pull out the pulley shaft,
just enough to free the pulley.
Diagonals to be within 1/4“
Z
Z
Side to side distance Z to be identical
