John Bean EELR529A - Cables

- 28 -
10.2 CABLES
ITEM#
SOE PART#
CL PART#
QTY
DESCRIPTION
1
EAA0485V10A
-
1
STEEL ROPE FRONT RIGHT ASSY
2
EAA0485V09A
-
1
STEEL ROPE FRONT LEFT ASSY
3
EAA0485V11A
-
1
STEEL ROPE REAR RIGHT ASSY
4
EAA0485V08A
-
1
STEEL ROPE REAR LEFT ASSY
5
1-23288A
40147
8
HEX NUT 7/8-9 UNC ZINC
7
1-23388A
B44015
2
M27 HEX JAM NUT
8
EAS2194V05A
40392-01-00
1
SLEEVE TUBE WELDMENT
9
EAM0155V81A
B40473
1
CABLE RETAINER STRAP
10
EAM0155V79A
B40474
1
CABLE RETAINER WELD
Replace all worn, damaged, or broken parts with parts approved by Snap-on Equipment.
Contact 1-800-225-5786
Figure 25
